• BUILT-IN ANTENNAS
Built-In
Antennas for Easy Setups, Efficient Shooting, and Different Shooting
Applications
• 300FT TRANSMISSION RANGE WITH 0.08S MINIMUM LATENCY
Up to 300ft Hassle-Free and Reliable Range for Wireless Video and Audio
Transmission
0.08S Lowest Achievable Latency for Real-Time Monitoring
• THUMBWHEEL SWITCH MENU
Better Using Experience with the
Multi-Functional Clickable Thumbwheel Switch
• MULTIPLE POWER OPTIONS
Supports 5-12V Wide Voltage Power Supply, Including Various L-Series
Batteries, Different Power Banks, and Type-C (5V/2A) Charging
• HDMI
IN & LOOPOUT
HDMI Input and loopout on TX, and Dual HDMI Outputs on RX
• SIDE OLED
Side OLED Provides Easy Access to Power Status, Channel
Scan, and Other OLED Display Information for Both Vertical or Horizontal
Installation Methods
• REAL-TIME APP MONITORING
Supports up to 3
Phones / Tablets Real-Time Monitoring with Pro Monitor Features, such as
Waveform, Focus Peaking, Zebra, ZOOM, 3D Luts, etc.
• FIRMWARE UPDATE
& CHANNEL SCAN ON APP
Easy and Quick Firmware Update & Channel Scan on
the HollyView APP
• THREE PRODUCT OPTIONS
STANDARD:
Built-in antennas on both TX and RX for convenient packing and installation
ENHANCED: External antennas and anti-collision design on TX
for complex shooting environments
SINGLE TRANSMITTER:
Loopout HDMI caters the need for on-camera external monitoring
|
Transmitter |
|
Interface |
HDMI Input (Type A female)
HDMI Loopout (Type A female)
2 Antenna port (RP-SMA male)
USB Type-C |
|
Supply Interface |
USB Type-C Supply: 5V/2A
Battery Supply: 5-12V DC |
|
Power Consumption |
<11W |
|
Weight |
136g |
|
Size |
(L x W x H): 110*61*21 mm,
not include battery plate |
|
Input/Output Video Format |
HDMI: 480P60,
576P50,
720P50/59.94/60
1080i50/59.94/60
1080P23.98/24/25/29.9/30
1080P50/59.94/60 |
|
Modulation Mode |
OFDM |
|
Frequency Band |
5GHz |
|
Transmission Power |
Maximum 21dBm |
|
Lowest Transmission Latency |
0.08s |
|
Receiver Sensitivity |
/ |
|
Bandwidth |
20MHz |
|
Receiver |
|
Interface |
HDMI Output (Type A female)
USB Type-C |
|
Supply Interface |
USB Type-C Supply: 5V/2A
Battery Supply: 5-12V DC |
|
Power Consumption |
<4W |
|
Weight |
128.5g |
|
Size |
(L x W x H): 110*61*21 mm,
not include battery plate |
|
Input/Output Video Format |
HDMI:
480P60,
576P50,
720P50/60
1080i50/60
1080P23.98/24/25/30
1080P50/60 |
|
Modulation Mode |
OFDM |
|
Frequency Band |
5GHz |
|
Lowest Transmission Latency |
0.08s |
|
Receiving Sensitivity |
-80dBm |
|
Bandwidth |
20MHz |
- Transmitter*1
- Receiver*1
-
Antennas*3
- User Guide*1
- Expansion Accessory*1
- Cold shoe*1
- USB Type-A to Type-C Data cable*1
|
