Hollyland 2/4 Wire Converter

Hollyland 2/4 Wire Converter

Home > Hollyland > 2/4 Wire Converter

Hollyland 2/4 Wire Converter for Hollyland SYSCOM 1000T to connect to 2-w wired Intercom System

Product Code: 2/4WIRECONVERTER

Buy Sell Sales Hollyland Mars400 Transmission System

7% Goods Service Tax (GST) will be imposed over the total invoice value if purchased locally in Singapore. However if you are a tourist visiting Singapore, this GST amount can be refunded at the Changi International Airport Departure Hall GST Refund Centre before departure with goods within 30 days from the date of purchase. Please note that only Tourists who have met the Tourist Refund Scheme's conditions and eligibility criteria can claim for the GST refund. Visit the following link for GST Guide for Visitors on Tourist Refund Scheme. https://www.iras.gov.sg/IRASHome/GST/Consumers/Tourist-Refund-Scheme

2/4 Wire Converter: Overview
Specifications
In the Box

2/4 Wire Converter for Hollyland SYSCOM 1000T to connect to 2-w wired Intercom System
One Button for Echo Processing
One button especially designed for echo processing with the Digital Signal Processing (DSP) technology for echo elimination, easy and convenient.

4W Audio Gain Adjustment
±6 ultra high adjustment range to effectively adjust the volume of both the wired and wireless system

High-Definition Sound Quality
Providing the possibility to interconnect with several wired and wireless intercom systems still with high-definition sound quality

4 Sets Combination for 1U Standard Setup
Supports standard 1/4 U structure accessory for 4 sets combination of 2/4 wire connections, for flexible daisy-chain and broader communication coverage

2-Wire Connection for Direct Power Supply
Direct power supply from the 12~36V 2-wire interface connection with the wired system, no additional power supply needed

220Ω Terminating Resistor Switch
The 220Ω terminating resistor switch supports effective interconnection between SYSCOM 1000T and different models of Datavideo wired intercom systems

Distance Compensation Switches
Two distance compensation switches for easy distance setup to meet up to 200m cable length between the wired system and the converter

Voltage & Static Protection
The voltage protection design effectively prevent damage to the equipment by overvoltage input. ±6000V Electrostatic Discharge (ESD) test to effectively avoid ESD damage in dry or humid environments

Excellent Compatibility
The 2 wire interface is compatible with ClearCom, RTS, Datavideo and other types of wired intercom systems

Interface	3-pin XLR Female 2-Wire Interface 3-pin XLR Male 2-Wire Interface 3-pin XLR Female 4-Wire Input Interface 3-pin XLR Male 4-Wire Output Interface
Power Supply	12~36V 2-Wire DC Input
2-Wire Output	Noise: <-68dBu Matching Impedance: 104-240Ω Frequency Response: 100~5kHz±3dB Distortion: <1% @1kHz S/N Ratio: >55dB @ -12dBu
2-Wire Input	Maximum Uncompressed level: >6dBu Input Impedance: >10K 2-Wire Input to 4-Wire Ouput Gain: 12dB±1dB
4-Wire Output	Noise: <-60dBu Matching Impedance: >400Ω Frequency Response: 100~5kHz±3dB Distortion: <1% @1kHz S/N Ratio: >55dB @ 0dBu
4-Wire Input	Maximum Uncompressed level: >18dBu Input Impedance: >10K 2-Wire Input to 4-Wire Ouput Gain: 12dB±1dB
Power Consumption	<1.5W
Dimension	10912043 mm
Weight	Around 520g
