Vaxis ATOM 600 KV Kit for RED KOMODO

Vaxis ATOM 600 KV Kit for RED KOMODO

Product Code: ATOM 600 KV

Buy Sell Sale Vaxis ATOM 600 KV Kit

review button

• Designed for KOMODO
• Adjustable battery plate
• Smart fan
• SDI/HDMI Loop Out
• 0.08s Latency
• Smart Channel Scan
• App monitoring
• Atom compatible

Vaxis ATOM 600 KV offers a 600 feet (182.8m) line of sight transmission range, with a claimed latency of less than 80ms. It also features an OLED display, power pass-thru, and an SDI/HDMI loop-out.

Vaxis ATOM600 KV is a versatile modular video transmitter integrating wireless transmission and adjustable battery mounting plate.

• Transmitter unit transmits up to 1080p60 wireless video up to 600′ line of sight
• Transmits with less than 80 ms latency
• Transmitter features one SDI input and SDI and HDMI loop outputs; receiver features one SDI and one HDMI output
• TX powers using a single, separately available V-mount battery that passes power through to the dual battery plate;  RX powers using a USB Type-C power source or using its L-series battery plate•
• Multicast support for transmitting video via Wi-Fi to up to three iOS devices running the Vaxis Vision app
• Adjustable cooling fan that can be turned on and off
• Customized battery plate for Red Komodo, power pass-thru
• Adjustable horizontal/vertical plate installation
• 600ft transmission range, for long-term REC and streaming stability
• Less than 80ms latency
• SDI / HDMI loop out
• Built-in HDMI & SDI signal converter
• Real-time APP monitoring
• Supports 13 channels, auto channel scan, and selection
• Smart fan for temperature control
• OLED screen for easy information access
• Scan the QR code to monitor
• OTA / APP firmware upgrade
• Passcode protection
• Audio-video 100% in sync
• Switch by your needs: image prior / latency prior
• Supports up to 1080p 60fps/1080i 60
• USB-C port for firmware upgrade and 5V/2A power output

Interface SDI Input; SDI / HDMI Loop output
Voltage 6-18V
Power Consumption < 6.5w
HDMI Output Video Format 1080p@24/25/30/50/60Hz 1080i@50/60Hz 1280*1024@60Hz 720p@50/60Hz
SDI Input Video Format 1080psf23.98/24/25/29.97/30Hz 1080p@23.98/24/25/29.97/30/50/59.94/60Hz 1080i@50/59.94/60Hz 720p@50/60Hz
SDI Output Video Format 1080psf23.98/24/25/29.97/30Hz 1080p@23.98/24/25/29.97/30/50/59.94/60Hz 1080i@50/59.94/60Hz 720p@50/60hz
Weight 400g
Dimensions 96.5 x 74 x 50.4 mm
Frequency 5GHz
Transmission Power 17dBm
Delay 80ms

• 1*Atom 600 KV TX
• 1*Atom 500 SDI RX
• 1* 39” SDI Cable
• 1* 12” SDI Cable
• 2* Radar Antenna
