FC-2000,
Audio Format Transcoder / SRC FC2000
|
|
|
|
|
The FC-2000
MultiCoder is a broadcast quality universal transcoder for analog
and digital audio signals. It simultaneously converts between any
of the most popular digital and analog audio formats and sampling
rates.
Typical
Applications:
-
Broadcast and
production studios.
-
Professional audio
post-production studios.
-
Digital / analog
audio authoring and production.
|
|
|
FEATURES
|
|
-
S/N Ratio -
85dB.
-
Bi-directional -
Converts any analog or digital audio format and sampling rate to
any other analog or digital format and sampling rate
-
Reclocking &
Equalization - Automatic prior to conversion.
-
Standards - AES/EBU,
AES-ID3, S/PDIF, Toslink Optical, balanced (analog) stereo
audio.
-
Sampling Rate
Conversion - 32, 44.1, 48, and 96kHz.
-
Switching
Synchronization - Synchronize either to external video or AES/EBU
reference inputs.
-
Conversion Ratio
(A/D & D/A) - 12dBFS, 16dBFS, 18dBFS, 20dBFS, 24dBFS
(selectable).
-
System Bit Selection
- Professional or consumer (selectable).
-
Standard 19”
Rack Mount Size - 1U.
|
|
|
SPECIFICATIONS
|
|
|
INPUTS: |
Analog balanced - on an XLR-F
connector 20dB max on 30KΩ. AES/EBU 110Ω - on an XLR-F,
transformer coupled. AES-ID3 75Ω on a BNC connector,
transformer coupled. S/PDIF 75Ω on an RCA connector. Optical
- Toslink. |
|
|
OUTPUTS: |
Analog balanced on an XLR-M
connector 20dB max. AES/EBU 110Ω on an XLR-M connector,
transformer coupled. AES-ID3 75Ω on a BNC connector,
transformer coupled. S/PDIF 75Ω on an RCA connector. Optical
- Toslink. |
|
|
REFERENCE INPUTS: |
AES/EBU 110Ω - on XLR-F,
transformer coupled. Video 75Ω – BNC
connector. |
|
|
DYNAMIC RANGE: |
> 80dB in both
directions. |
|
|
BANDWIDTH (-3dB): |
20 kHz. |
|
|
SAMPLE RATES: |
32, 44.1, 48, 96
kHz. |
|
|
S/N RATIO: |
85 dB. |
|
|
CONTROL: |
Input signal selector, reference
signal selector, conversion rate. |
|
|
AUDIO THD + NOISE: |
0.02% unweighted. |
|
|
POWER SOURCE: |
230VAC 50/60 Hz (115VAC USA)
20VA. |
|
|
DIMENSIONS: |
19 inch (W), 7 inch (D), 1U (H) rack
mountable. |
|
|
WEIGHT: |
2.5 kg (5.5 lbs)
approx. |
|
|
ACCESSORIES: |
Power cord. |
|
| |
|
|
|
|
