Miller Arrow F^X3 Fluid head

Product Code: ARROWFX3

Features

Compact, lightweight and versatile.
5 selectable positions of fluid pan and tilt drag +0.
16 position CB PlusTM counterbalance system.
Wide payload range 1-19kg (2.2-41.8lbs).
Fluid drag system with smooth start and soft stop technology & balanced diagonal transitions.
Controls “all in one location” design for fast, easy and practical use.
Illuminated bubble level and pan-tilt drag controls.
Precise floating pan-tilt calliper locks ensure bounce free on-off performance.
Quick release, 120mm sliding camera platform with camera plate (euro).
Removable ball level stud allows for flat base mounting with 3/8” screw thread.
1225 Mitchell base adaptor with clamp.
Robust construction for rugged outdoor shooting conditions.
Optional second pan handle mount.
Side mounting points for viewfinders and accessories.
Three-year warranty.

Arrow F^X3: Overview
Specifications

Following in the tradition and reputation of the worldrenowned Arrowx series, the all-new ArrowFx is designed to be employed in television where augmented reality effects are inserted into the live broadcast and for cinema quality visual effects in the production of feature films and commercials.

Featuring a wide payload range, precision fluid drag and Miller’s innovative 16 position CB PlusTM counterbalance system, ArrowFx 3 delivers the flexibility, speed of set up and accuracy of shot.

Each arrowFX model comes with a 120mm sliding travel plate to help quickly rebalance changing camera payloads. Precision pan-tilt movements, supported by ball bearings, help deliver silky smooth starts and fluid, soft-stop actions. Precise floating pan-tilt calliper locks ensure bounce-free on-off locking. Illuminated controls allow users to work no matter what conditions they are in.

The robust, high resolution magnetic encoders integrated into the fluid head, precisely monitor and communicate, in real time, the positioning of the pan and tilt mechanisms along their axes.

Pan Resolution 1.6 million counts per 360°
Tilt Resolution 1 million counts per 360°.

Arrow FX 3 is designed for lighter cameras used in ENG, documentaries and EFP applications.

ArrowFx comes in three models, ArrowFx 3, ArrowFx 5 and ArrowFx 7.

Payload range	1-19kg (2.2-41.8lbs)
Pan-tilt drag	5 selectable fluid drag positions + 0
Counterbalance	16 selectable positions
Pan-tilt locks	Positive lock calliper brake system
Tilt range	+90°/-75°
Pan range	360°
Pan Resolution	1,589,246 counts per 360 degrees
Tilt Resolution	491,520 counts per 180 degrees
Output	RJ45 receptacle, Cat5
Power Requirements	5 VDC +/- 10%
Camera platform	Quick release camera plate with 1⁄4” and 3/8” screws
Sliding range	120mm (4.7”)
Mounting base	Ø100mm (3.9”) ball levelling with 3 x M5 holes for flat base mounting
Height above bowl	( ”)
Illuminated controls	Bubble level, pan-tilt drag controls
Pan handle	696 Telescopic 390 to 590mm (15.4 to 23.2”)
Temperature range	-40° to +65°C (-40° to +149°F)

Miller Arrow F^X3 Fluid Head
