Sony FCB-EX985E Block Camera
Product Code: FCBEX985E
Features
• StableZoom Image Stabilization
• Digital Output (ITU-R BT656)
• Sodium Vapor Lamp
• Temperature Readout
• Color Enhancement
• White Balance: Outdoor Auto Mode
The Sony FCB-EX985E block camera combines superb picture quality with high zoom capabilities, up to 336x with optical zoom. Ideally suited for IP-ready
monitoring applications, the FCB-EX985E incorporates ¼-type SuperHAD II CCD with Interlace Scan with a digital output (ITU-R BT656). In addition, the FCB-EX985E features StableZoom
Image Stabilization and Sodium Vapor Lamp Mode to reduce the yellowing of images. Additional color enhancement features are ideally suited for low vision applications.
|
| Camera Specifications |
| Image Device |
1/4 type SuperHAD II CCD (IS) |
| Effective Pixels |
380,000 |
| Digital Zoom |
12x (336x with optical zoom) |
| Horizontal Viewing Angle |
55.8° (wide end) to 2.1° (tele end) |
| Minimum Object Distance |
10 mm* (wide) ~ 1500 mm (tele) *Default: 290 mm |
| Sync System |
Internal/External (V-Lock) |
| Electronic Shutter |
1/1 to 1/10,000 s, 22 steps |
| White Balance |
Auto, ATW, Indoor, Outdoor Auto, Sodium Vapor Lamp (fix/auto), One-push, Manual |
| Gain |
Auto/Manual/Max. Gain Limit (-3 to +28 dB, 2 dB steps) |
| Privacy Zone Masking |
Spherical |
| Character Generator |
20 characters/line, max. 11 lines |
| Picture Effects |
E-Flip
Nega Art
Black & White
Mirror Image
Color Enhancement |
| Focus System |
Auto (Sensitivity: normal, low)
One-push AF
Manual
Infinity
Interval AF
Zoom trigger AF
Focus Compensation in ICR on |
| Video output Specifications |
| Lens Value |
28x optical zoom; f = 3.5 mm (wide) to 98.0 mm (tele) |
| S/N Ratio |
More than 50 dB |
| Minimum Illumination |
0.3 lx (typical) (F1.35 50 IRE) |
| Video Output |
Analog: VBS: 1.0 Vp-p (sync negative), Y/C
Digital: Y/Cb/Cr 4:2:2: (ITU-R BT656 Style) |
| Signal System |
NTSC |
| Horizontal Resolution |
550 TV Lines |
| Interface Specifications |
| Camera Control Interface |
VISCA (TTL signal level) Baud Rate: 9.6Kb/s, 19.2Kb/s, 38.4Kb/s
Stiop bit: 1/2 bit selectable |
| General Specifications |
| Dimensions (W x H x D) |
50.0 x 57.5 x 88.5 mm |
| Weight |
230 g |
| Operating Temperature |
-5°C to 60°C |
| Power Consumption |
22.6 W (motors active: 4.4 W) |
| Power Requirements |
6.0 V ~ 12.0 V DC |
|
|
