Sony FCB-EX1020P PAL Color Block Camera
Product Code: FCBEX1020P
Features
• 1/4 type ExView HAD CCD
• True Progressive Scan
• IP-Ready Digital Output (ITU-R BT656)
• Temperature readout
• Color Enhancement
• Auto Wide-D Mode
• StableZoom Mode Image Stabilization
• Outdoor Auto Mode
• Sodium Vapor Lamp Mode
• 2D/3D Noise Reduction
• Auto ICR
• Spherical Zone Masking
• Motion Detection
• Alarm
• Slow AE Response
Sony continues to prevail on the cutting edge of the imaging industry with the latest addition to the FCB camera series. The FCB-EX1020P PAL color block camera incorporates
a 1/4 type ExView HAD CCD and features True Progressive Scan with exceptional picture quality and high zoom capabilities - 432x combined digital and optical zoom. In addition, the
FCB-EX1020P is the first in this exceptional camera series with IP-Ready digital output, uniting several new and upgraded features with its renowned FCB performance and outstanding
picture quality.
- True Progressive Scan: The FCB-EX1020P is ideally suited for IP monitoring applications, adopting a Progressive Scan mode to provide smooth and clear images without interface
artifact effects when viewing details in a moving image (i.e., license plates of moving vehicles, a person running). All the processing is done by the PS from the CCD readout, signal to
processing to video output.
- StableZoom Mode: The FCB-EX1020 adopts a new method of Image Stabilization by using the digital zoom. When the optical zoom reaches a certain ratio,
the Image Stabilization function starts to work by gradually combining with the digital zoom. The area is enlarged by the digital zoom and absorbs shaky movements.
- Digital Output
(ITU-R BT656) By using the digital interface, the quality of the FCB-EX1020’s video signal does not deteriorate. This can lead to cost savings due to the direct connection to
codecs/systems without the need for any additional components.
|
Camera Specifications |
Image Device |
1/4 type EXviewHAD CCD (PS) |
Effective Pixels |
400,000 |
Digital Zoom |
12x (432x with optical zoom) |
Horizontal Viewing Angle |
57.8° (wide end) to 1.7° (tele end) |
Sync System |
Internal/External (V-Lock) |
Electronic Shutter |
1/1 to 1/10,000 s, 22 steps |
White Balance |
Auto, ATW, Indoor, Outdoor, One-push, Manual |
Gain |
Auto/Manual (-3 to +28 dB, 2 dB steps) |
Wide Dynamic Range |
Auto mode, IS/PS mode |
Backlight Compensation |
On/Off |
Privacy Zone Masking |
On/Off (24 positions, 8 positions per screen) 14 Colors + Mosaic |
Character Generator |
Mode: On/Off (White Balance, Gain, etc.) Title: 11 Lines (20 characters per line) |
Flicker Control |
Auto |
Focus System |
Auto (Sensitivity: normal, low) One-push AF Manual Infinity Interval AF Zoom trigger AF |
Camera Operation / Zoom Switch |
Zoom Tele, Zoom wide |
Picture Effects |
E-Flip Nega Art Black & White Mirror Image Color Enhancement |
Video output Specifications |
Lens Value |
36x optical zoom |
S/N Ratio |
More than 50 dB |
Minimum Illumination |
1.4 lx (typical) (F1.6 50 IRE) |
Video Output |
VBS: 1.0 Vp-p (sync negative), Y/C
|
Signal System |
PAL |
Horizontal Resolution |
540 TV Lines |
Interface Specifications |
Camera Control Interface |
VISCA (TTL signal level) Baud Rate: 9.6Kb/s, 19.2Kb/s, 38.4Kb/s Stop bit: 1/2 bit selectable |
General Specifications |
Dimensions (W x H x D) |
50.0 mm x 57.5 mm x 87.9 mm |
Weight |
230 g |
Operating Temperature |
-5°C to 60°C |
Storage Temperature |
-20° to 60° C (-4° to 140° F) |
Power Consumption |
6 to 12 V DC/ 3.0 W (motors inactive, 4.0 W (motors active) |
|
|
