Sony FCB-EX48EP Block Camera
Product Code: FCBEX48EP
Features
• Digital output (ITU-R BT656)
• Color Enhancement
• Outdoor Auto Mode
• Sodium Vapor Lamp
• 18x Optical Zoom
- Digital output (ITU-R BT656)
- Color Enhancement
- Outdoor Auto Mode
- Sodium Vapor Lamp
- 18x Optical Zoom
Highlights:
- Digital Output
(ITU-R BT656): By using the digital interface, the quality of the FCB-EX48EP camera's video signal does not deteriorate. This can lead to cost savings due to the direct connection to
codecs/systems without the need for any additional components.
- Temperature Readout: The value of the internal temperature of the FCB-EX48EP camera can be read out via the VISCA™
protocol. When checking the internal temperature of equipment (i.e., speed dome unit), it is possible to use this data to turn a fan or heater on/off inside the equipment as needed.
- Color
Enhancement: Ideally suited for low vision applications, the new color enhancement options of the FCB-EX48EP can make reading text and pictures less challenging. Available options include
monochrome, binary, inverted and enhanced color modes.
|
| Camera Specifications |
| Image Device |
1/4 type CCD (IS) |
| Effective Pixels |
440,000 |
| Digital Zoom |
12x (216x with optical zoom) |
| Horizontal Viewing Angle |
48.0° (wide end) to 2.8° (tele end) |
| Minimum Object Distance |
10 mm* (wide) ~ 800 mm (tele) *Default: 290 mm |
| Sync System |
Internal/External (V-Lock) |
| Electronic Shutter |
1/1 to 1/10,000 s, 22 steps |
| White Balance |
Auto, ATW, Indoor, Outdoor Auto, Sodium Vapor Lamp (fix/auto), One-push, Manual |
| Gain |
Auto/Manual/Max. Gain Limit (-3 to +28 dB, 2 dB steps) |
| EV Compensation |
Yes |
| Privacy Zone Masking |
Spherical |
| Character Generator |
20 characters/line, max. 11 lines |
| Picture Effects |
E-Flip
Nega Art
Black & White
Mirror Image
Color Enhancement |
| Exposure Control |
Auto
Manual
Priority Mode (shutter priority & iris priority)
Bright
EV Compensation
Slow AE |
| Video output Specifications |
| Lens Value |
18x optical zoom; f = 4.1 mm (wide) to 73.8 mm (tele) |
| S/N Ratio |
More than 50 dB |
| Minimum Illumination |
0.7 lx (typical) (F1.4 50 IRE) |
| Video Output |
Analog: VBS: 1.0 Vp-p (sync negative), Y/C
Digital: Y/Cb/Cr 4:2:2: (ITU-R BT656 Style) |
| Signal System |
PAL |
| Horizontal Resolution |
550 TV Lines |
| Interface Specifications |
| Camera Control Interface |
VISCA (TTL signal level) Baud Rate: 9.6Kb/s, 19.2Kb/s, 38.4Kb/s
Stiop bit: 1/2 bit selectable |
| General Specifications |
| Dimensions (W x H x D) |
50.0 x 57.5 x 88.5 mm |
| Weight |
230 g |
| Operating Temperature |
-5°C to 60°C |
| Power Consumption |
1.5 W (motors inactive: 2.5 W) |
|
|
