Sony FCB-EX995EP 1/4-type EXview HAD CCD Block Camera
Product Code: FCBEX995EP
Discontinued
Features
• True Progressive Scan
• Auto Wide-D Mode
• StableZoom Image Stabilization
• Sodium Vapor Lamp Mode
• Digital Output (ITU-R BT656)
• Temperature Readout
• Color Enhancement
- True Progressive Scan - Auto Wide-D Mode - StableZoom Image Stabilization - Sodium Vapor Lamp Mode - Digital Output (ITU-R BT656) -
Temperature Readout - Color Enhancement
|
Camera Specifications |
Image Device |
1/4 type EXview HAD CCD (PS) |
Effective Pixels |
440,000 |
Digital Zoom |
12x (432x with optical zoom) |
Horizontal Viewing Angle |
55.8° (wide end) to 2.1° (tele end) |
Minimum Object Distance |
10 mm* (wide) ~ 1500 mm (tele) *Default: 320 mm |
Sync System |
Internal/External (V-Lock) |
Electronic Shutter |
1/1 to 1/10,000 s, total 22 steps |
White Balance |
Auto, ATW, Indoor, Outdoor Auto, Sodium Vapor Lamp (fix/auto), One-push, Manual |
Gain |
Auto/Manual/Max. Gain Limit (-3 to +28 dB, +2 dB steps) |
Wide Dynamic Range |
Auto mode IS/PS mode |
Privacy Zone Masking |
Spherical |
Character Generator |
Title: 20 characters/line, max. 11 lines |
Focus System |
Auto (Sensitivity: normal, low) One-push AF Infinity Manual Interval AF Zoom trigger AF Focus Compensation in ICR On |
Camera operation / Zoom Switch |
Key Switch Control Zoom Tele Zoom Wide |
Picture Effects |
E-Flip Nega Art Black & White Mirror Image Color |
Video output Specifications |
Lens Value |
36x optical zoom; f = 3.4 mm (wide) to 122.4 mm (tele) |
S/N Ratio |
More than 50 dB |
Minimum Illumination |
1.4 lx (typical) (F1.6 50 IRE) |
Video Output |
Analog: VBS: 1.0 Vp-p (dync negative), Y/C Digital: Y/Cb/Cr 4:2:2: (ITU-R BT656 Style) |
Signal System |
NTSC |
Horizontal Resolution |
550 TV Lines |
Interface Specifications |
Camera Control Interface |
VISCA (TTL signal level) Baud Rate: 9.6Kb/s, 19.2Kb/s, 38.4Kb/s Stiop bit: 1/2 bit selectable |
General Specifications |
Dimensions (W x H x D) |
50.0 x 57.5 x 88.5 mm |
Weight |
230 g |
|
|
