3532-S Large
Diaphragm Stereo Kit w. 4041-S
|
| |
Product
Code:3532SStereo
|
Model:3532S
Other Microphones -
Microphone Kits
The DPA 3532-S is a complete A-B
Stereo Kit consisting of two carefully factory-matched
omnidirectional Large Diaphragm Microphones 4041-S with 130 V solid
state preamplifiers in a discrete class A design.
|
|
| |
|
|
| |
|
| |
|
3532-S Large Diaphragm Stereo
Kit w. 4041-S
-
the ultimate choice for
all professional A-B Stereo recordings
-
exceptionally low noise
floor
-
microphones matched
within 1 dB on both frequency response, sensitivity and self
noise
The DPA 3532-S is a
complete A-B Stereo Kit consisting of two carefully factory-matched
omnidirectional Large Diaphragm Microphones 4041-S with 130 V solid
state preamplifiers in a discrete class A design.
Included is also the Hi-Voltage Microphone Amplifier Type HMA5000
and a Stereo Boom all packed with cables in a handy carrying case
with a foam insert. Please refer to Related products for full
description of accessories.
The specially selected microphones are matched within 1 dB on both
frequency response, sensitivity and self noise. The maximum phase
response difference from 50 Hz to 20 kHz is 10°. The frequency
response from 10 Hz to 20 kHz with a 4-6 dB soft boost around 8 kHz
matches the response of the highly acclaimed 4040 Hybrid
Microphone.
The two 4041-S are powered via the standard HMA5000
Microphone Amplifier, creating an A-B stereo microphone system that
offers a totally transparent audio path with an exceptionally low
noise floor of maximum 7 dB(A) and an SPL handling capability of
144 dB SPL peak.
This is the ultimate choice for all professional A-B Stereo
recordings.
|
|
General
Specifications |
| Directional
characteristics: |
Omnidirectional |
| Principle of
operation: |
Pressure |
| Cartridge type: |
24 mm (1 in) condenser w. stainless steel
diaphragm |
| Frequency
range,
± 2 dB: |
10 Hz - 20 kHz with 4 - 6 dB
soft boost at 8 kHz |
| Sensitivity, nominal+/- 2 dB
at 250 Hz: |
90 mV/Pa |
| Equivalent
noise level A-weighted: |
Max. 7 dB(A) re. 20
µPa |
| Equiv. noise level ITU-R
BS.468-4: |
Max. 19 dB |
| S/N ratio
(A-weighted), re. 1 kHz at 1 Pa (94 dB SPL): |
87 dB |
| Total harmonic distortion
(THD): |
< 1% THD up to 126 dB SPL
peak |
| Dynamic
range: |
119 dB |
| Max. SPL, peak before
clipping: |
144 dB |
| Output
impedance: |
Matches HMA5000
input |
| Cable drive
capability: |
From microphone to HMA5000: up to 20 m (66 ft).
From HMA5000: up to 300 m (984 ft) |
| Power
supply: |
HMA5000 |
| Connector: |
7-pin modified XLR-M (High
Voltage) |
| Weight: |
190 g |
| Phase deviation for
kit: |
<5° |
| Length: |
170 mm (6.7
in) |
| Capsule diameter: |
24 mm (1 in) |
| Matching tolerance
(frequency response and sensitivity): |
±5 dB (20 Hz - 20
kHz) |
|
| |
|
|
|
|
|
