Metrics |
Dimensions (W x H x
D) |
136.8 x 98.5 x 130.7
mm |
Dimensions (W x H x
D) |
(5.39 x 3.88 x 5.15
inch) |
Weight |
Approx. 780 g without Battery and SD
Memory Card (1.72 lb) |
Weight |
Approx. 831 g with Battery and SD
Memory Card (1.83 lb) |
Optics |
Pixels |
Camera Effective
Pixels |
20.1 Megapixels |
Sensor |
Sensor Size / Total Pixels /
Filter |
1-type High Sensitivity MOS Sensor /
Total Pixel Number 20.9 Megapixels / Primary Color
Filter |
Lens |
Aperture |
F2.8 - 4.0 / Multistage Iris
Diaphragm (Still Image: F2.8 - 8.0 (W), F4.0 - 8.0 (T), Motion
Picture: F2.8 - 11.0 (W), F4.0 - 11.0 (T)) |
Optical Zoom |
16x |
Focal Length |
f = 9.12 - 146mm |
Focal Length |
(27 - 432mm in 35mm equiv. in
4:3) |
Focal Length |
(25 - 400mm in 35mm equiv. in
3:2) |
Focal Length |
(26 - 416mm in 35mm equiv. in
16:9) |
Focal Length |
(32 - 512mm in 35mm equiv. in
1:1) |
Focal Length |
(26 - 416mm in 35mm equiv. in 16:9
video recording / O.I.S. Off / Level Shot function
Off) |
Focal Length |
(28 - 448mm in 35mm equiv. in 16:9
video recording / O.I.S. On / Level Shot function
Off) |
Focal Length |
(31 - 496mm in 35mm equiv. in 16:9
video recording / O.I.S. On / Level Shot function
On) |
Focal Length |
(37 - 592mm in 35mm equiv. in 4K
video recording) |
Extra Optical Zoom
(EZ) |
22.4x (3:2 / 10M (M)), 32x (3:2 / 5M
(S)) |
Intelligent Zoom |
32x |
Lens |
LEICA DC
VARIO-ELMARIT |
Lens |
15 elements in 11
groups |
Lens |
(5 Aspherical Lenses / 8 Aspherical
Surfaces / 4 ED Lenses) |
Changing of Zoom
Speed |
5-Speed Zoom |
Optical Image Stabilizer/Five Axis
Correction |
HYBRID O.I.S. +* / Yes* * Except for
the 4K video recording. |
Digital Zoom |
Max. 4x |
Conversion Lens
Compatibility |
- |
Focus |
Focusing Area |
Normal: Wide 30 cm - infinity / Tele
100 cm - infinity |
Focusing Area |
AF Macro / MF / Intelligent Auto /
Motion Picture: Wide 3 cm - infinity / Tele 100 cm -
infinity |
AF Assist Lamp |
Yes (On / Off) |
Focus |
AFS (Single) / AFF (Flexible) / AFC
(Continuous) / MF |
Focus |
Normal / AF Macro / Macro Zoom, Quick
AF On / Off (on in Intelligent Auto), Low Light AF, AF/AE Lock
Button, AF Area Select, AF Tracking, Eye Sensor AF, Focus Peaking,
One Shot AF (Set the Fn button in custom menu to
AF-ON) |
AF Metering |
Face/Eye Detection / Tracking /
49-area / Custom Multi / 1-area (flexible / scalable) /
Pinpoint |
Shutter |
Shutter Speed |
Still Image: |
Shutter Speed |
Approx. 60 - 1/4,000 sec (Mechanical
Shutter) |
Shutter Speed |
Approx. 1 - 1/16,000 sec (Electronic
Shutter) |
Shutter Speed |
Bulb (Approx. 120
sec) |
Shutter Speed |
Motion Picture: |
Shutter Speed |
Approx. 1/25 - 1/16,000
sec |
Shutter Speed |
Approx. 1/2 - 1/16,000 sec (Creative
Video Mode / MF Mode) |
Finder |
Viewfinder |
0.39" OLED LVF (Live View Finder)
(2359K dots), Field of View: Approx. 100%, |
Viewfinder |
Magnification: Approx. 1.88x / 0.7x
(35mm equiv.), Eye Sensor |
Recording |
File |
File Format |
Still Image: JPEG (DCF/Exif2.3) /
RAW, DPOF |
File Format |
Motion Picture: AVCHD,
MP4 |
Recording
Modes |
Mode Dial / Mode
Button |
Intelligent Auto, P, A, S, M,
Creative Video, C1 (Custom), C2 (Custom), Scene Guide, Creative
Control |
Creative Control mode |
Expressive, Retro, Old Days, High
Key, Low Key, Sepia, Monochrome, Dynamic Monochrome, Rough
Monochrome, Silky Monochrome, Impressive Art, High Dynamic, Cross
Process, |
Creative Control mode |
Toy Effect, Toy Pop, Bleach Bypass,
Miniature Effect, Soft Focus, Fantasy, Star Filter, One Point
Color, Sunshine (22 filters) |
Still Image Scene Mode / Scene
Guide |
Clear Portrait, Silky Skin, Backlit
Softness, Clear in Backlight, Relaxing Tone, Sweet Child's Face,
Distinct Scenery, Bright Blue Sky, Romantic Sunset Glow, Vivid
Sunset Glow, Glistening Water, Clear Nightscape, Cool Night Sky,
Warm Glowing Nightscape, |
Still Image Scene Mode / Scene
Guide |
Artistic Nightscape, Glittering
Illuminations, Handheld Night Shot, Clear Night Portrait, Soft
Image of a Flower, Appetizing Food, Cute Dessert, Freeze Animal
Motion, Clear Sports Shot, Monochrome, Panorama |
Continuous Shooting Mode
(Approx.) |
[AFS] SH: 50 frames/sec*, H: 12
frames/sec, M: 7 frames/sec (with Live View), L: 2 frames/sec (with
Live View) |
Continuous Shooting Mode
(Approx.) |
[AFC] H: 7 frames/sec, M: 7
frames/sec (with Live View), L: 2 frames/sec (with Live
View) |
Continuous Shooting Mode
(Approx.) |
* Electronic shutter
only. |
Motion Picture
Recording (*2) |
4K Video |
3840 x 2160 pixels, 25p (4K: 100Mbps
/ MP4) (Sensor Output is 25fps) (AAC) |
HD Video |
1920 x 1080 pixels, 50p (FHD: 28Mbps
/ AVCHD) (Sensor Output is 50fps) (Dolby) |
HD Video |
1920 x 1080 pixels, 24p (FHD: 24Mbps
/ AVCHD) (Sensor Output is 24fps) (Dolby) |
HD Video |
1920 x 1080 pixels, 25p (FHD: 24Mbps
/ AVCHD) (Sensor Output is 25fps) (Dolby) |
HD Video |
1920 x 1080 pixels, 50i (FHD: 17Mbps
/ AVCHD) (Sensor Output is 50fps) (Dolby) |
HD Video |
1920 x 1080 pixels, 50p (FHD: 28Mbps
/ MP4) (Sensor Output is 50fps) (AAC) |
HD Video |
1920 x 1080 pixels, 25p (FHD: 20Mbps
/ MP4) (Sensor Output is 25fps) (AAC) |
HD Video |
1280 x 720 pixels, 25p (HD: 10Mbps /
MP4) (Sensor Output is 25fps) (AAC) |
STD Video |
640 x 480, 25p (VGA: 4Mbps / MP4)
(Sensor Output is 25fps) (AAC) |
High Speed Video |
1920 x 1080 pixels, 25p (FHD: MP4)
(Sensor Output is 100fps) |
Continuous recordable
time (motion pictures) |
AVCHD |
Approx. 130 min (FHD/60p), Approx.
135 min (FHD/60i) |
MP4 |
Approx. 130 min (FHD) |
Actual recordable time
(motion pictures) |
AVCHD |
Approx. 65 min (FHD/60p), Approx. 70
min (FHD/60i) |
MP4 |
Approx. 65 min (FHD) |
Exposure
Parameters |
Exposure |
Program AE, Aperture Priority AE,
Shutter Priority AE, Manual |
Exposure Compensation |
1/3 EV step, +/-5 EV (+/-3 EV for
motion picture) |
Auto (AE) Bracketing |
3, 5, 7 frames in 1/3, 2/3 or 1 EV
Step, Max. +/-3 EV |
Light Metering |
Intelligent Multiple / Center
Weighted / Spot |
ISO Sensitivity |
Auto / i.ISO / 80* / 100* / 125 / 200
/ 400 / 800 / 1600 / 3200/ 6400 / 12800 / 25600* (* Extended
ISO) |
ISO Sensitivity |
(Changeable to 1/3 EV
step) |
Quality |
Still Picture
Recording |
[4:3] 4864x3648 (17.5M) (L) /
3456x2592 (9M) (M) / 2432x1824 (4.5M) (S) |
Still Picture
Recording |
[3:2] 5472x3648 (20M) (L) / 3888x2592
(10M) (M) / 2736x1824 (5M) (S) |
Still Picture
Recording |
[16:9]5472x3080 (17M) (L) / 3840x2160
(8M) (M) / 1920x1080 (2M) (S) |
Still Picture
Recording |
[1:1] 3648x3648 (13.5M) (L) /
2592x2592 (6.5M) (M) / 1824x1824 (3.5M) (S) |
Image Quality |
RAW / RAW+Fine / RAW+Standard / Fine
/ Standard |
White Balance |
Auto / Daylight / Cloudy / Shade /
Incandescent / Flash / White Set1 / White Set2 / White Set3 / White
Set4 / Color Temperature |
White Balance |
(2-axis Adjustable) |
Photo Style |
Standard, Vivid, Natural, Monochrome,
Scenery, Portrait, Custom, Cinelike D*, Cinelike V* * When Creative
Video mode is selected. |
Color Mode / Color
Effect |
- |
Picture Adjustment |
Contrast, Sharpness, Noise Reduction,
Saturation*, Filter Effect** * Except for Monochrome mode. ** For
Monochrome mode only. |
Aspect Bracketing |
- |
Other |
Digital Red Eye Correction (Red-Eye
Removal) |
Yes (On / Off) |
GPS |
- |
Wi-FI |
IEEE 802.11b/g/n |
Wi-FI |
2412 MHz - 2462 MHz (1-11
ch) |
Wi-FI |
WPA / WPA2 |
Wi-FI |
Infrastracture Mode / WPS / Wi-Fi
Direct |
Wi-FI |
Wi-Fi Button |
NFC |
ISO/IEC 18092, NFC-F (Passive
Mode) |
Zoom in Motion
Picture |
Yes |
Self Timer |
2 sec / 10 sec / 10 sec (3
images) |
Self Shot Mode |
- |
Playback |
Display |
Playback Mode |
All, Slideshow, Filtering Play
(Picture Only, Video Only, Category Selection, Select Date,
Favorite), Calendar |
Thumbnails / Zoomed
Playback |
12,30-thumbnails /
Yes |
Calendar Display / Dual- Image
Playback |
Yes / No |
Set Favorites / Rotate
Image |
Yes / Yes |
Show Histogram |
Yes |
Show Highlights |
Yes |
DPOF Print Setting / Set
Protection |
Yes / Yes |
Edit |
Retouch |
No |
RAW Processing |
Yes |
Resize / Cropping / Aspect Conv. /
Leveling |
Yes / Yes / No / No |
Copy / Title Edit / Text
Stamp |
No / Yes / Yes |
Cut Animation |
Yes |
Video Divide |
Yes |
PictBridge Support |
Single / Multi / All / DPOF /
Favorites |
Setup |
OSD language |
Japanese, English, German, French,
Italian, Spanish, Polish, Czech, Hungarian, Netherlandic, Turkish,
Portuguese, Finnish, Danish, Swedish, Greek |
Others |
Monitor |
LCD Monitor |
7.5cm (3.0") Free-Angle TFT Screen
LCD Display (921K dots), AR Coating |
LCD Monitor |
Field of View: Approx. 100%, Wide
Viewing-angle |
LCD Monitor |
Power Monitor mode, AUTO Power
Monitor mode |
Flash |
Built- in- Flash |
Auto*, Auto/Red-eye Reduction*,
Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow
Sync./Red-eye Reduction, Forced Off * For iA, iA+ mode
only. |
Built- in- Flash |
Flash Synchro: 1st / 2nd Slow
Sync. |
Built- in- Flash |
Synchronization for flash dimming and
exposure compensation |
Built- in- Flash |
0.3 - 13.5m (Wide / ISO Auto), 1.0 -
9.5m (Tele / ISO Auto) |
Media |
Recording Media |
SD Memory Card, SDHC Memory Card,
SDXC Memory Card (Compatible with UHS-I standard) |
Built- in- Memory |
- |
Audio |
Microphone / Speaker |
Stereo / Mono |
Interface |
Interface |
microHDMI, AV Output (PAL / NTSC),
USB (AV/USB Multi) |
Remote Input |
φ2.5mm for
Remote |
External Microphone
Input |
φ3.5mm for External
Microphone |
Power |
Power |
Li-ion Battery Pack (7.2V, 1200mAh,
8.7 Wh) (Included) |
Power |
AC Adaptor (Input: 110 - 240V AC)
(Included) |
Battery life
(approx.) |
360 pictures (CIPA
Standard)*1 |
Standard
Package |
Included Software |
PHOTOfunSTUDIO 9.5PE |
Included Software |
SILKYPIX Developer
Studio |
Included Software |
LoiLoScope (trial
version) |
Included Software |
Adobe Reader |
Standard Accessories |
Battery Charger, Battery Pack, USB
Cable, AC Cable, Lens Hood, Lens Cap, Hot Shoe Cover,
DVD |
NOTE |
*1. Recording conditions by CIPA
standard |
NOTE |
- Temperature: 23 oC (73.4 oF) /
Humidity: 50%RH when LCD monitor is on. |
NOTE |
- Using a Panasonic SDHC Memory
Card |
NOTE |
- Using the supplied
battery. |
NOTE |
- Starting recording 30 seconds after
the camera is turned on. (When the optical image stabilizer
function is set to [ON].) |
NOTE |
- Recording once every 30 seconds
with full flash every second recording. |
NOTE |
- Rotating the zoom lever from Tele
to Wide or vice versa in every recording. |
NOTE |
- The number of recordable pictures
varies depending on the recording interval time. |
NOTE |
- If the recording interval time
becomes longer, the number of recordable pictures
decreases. |
NOTE |
- CIPA is an abbreviation of [Camera
& Imaging Products Association]. |
NOTE |
*2. - These are standard times taken
at a temperature of 23 oC (73.4 oF) and a humidity of
50%RH. |
NOTE |
- The time available for recording
varies depending on the environment, the interval between
recordings, and the manner of use. |
NOTE |
- Actual recordable time is the time
available for recording when repeating actions such as switching
the power supply [ON] / [OFF], starting/stopping recording, zoom
operation etc. |
NOTE |
- Use a card with SD Speed Class with
"Class 4" or higher when recording motion pictures. |
NOTE |
- Use a card with SD Speed Class with
"UHS-I Speed Class 3 (U3)" when recording motion pictures with
[MP4] in [4K]. |
NOTE |
(SD speed class is the speed standard
regarding continuous writing.) |
NOTE |
- Maximum time to record motion
pictures continuously with [AVCHD] is 29 minutes 59
seconds. |
NOTE |
- Maximum time to record motion
pictures continuously with [MP4] in [4K] is 29 minutes 59
seconds. |
NOTE |
- Maximum time to record motion
pictures continuously with [MP4] in [FHD] [HD] [VGA] is 29 minutes
59 seconds or up to 4 GB. |
NOTE |
- Maximum time to record High Speed
motion pictures continuously is 7 minutes 59
seconds. |
