| General Specifications |
| Projector type |
3-Chip DLP projector |
| DLP Chip | Panel Size |
22.9 mm (0.9 in) diagonal (16:10 aspect ratio) |
| DLP Chip | Display Method |
DLP chip x 3 |
| DLP chip | Number of Pixels |
4,096,000 (2560 × 1600) × 3, total of 12,288,000 pixels,
49,152,000 (12,288,000 x 4) pixels when Quad Pixel Drive set to ON |
| Refresh rate |
240 Hz |
| Light Source |
Laser diodes |
| Light output |
20,000 lm/21,000 lm (Center) |
| Time until light output declines to 50 % |
20,000 hours (NORMAL) /24,000 hours (ECO) |
| Resolution |
4K+ (5120 x 3200 pixels) (Quad Pixel Drive: ON) |
| Contrast Ratio |
20,000:1 (Full On/Full Off, Dynamic Contrast Mode: 3) |
| Screen size [diagonal] |
1.78–25.4 m (70–1,000 in) with 16:10 aspect ratio
1.78–15.24 m (70–600 in) with the ET-D75LE8 / ET-D3LET80, 16:10 aspect ratio
3.05–15.24 m (120–600 in) with the ET-D75LE95, 16:10 aspect ratio |
| Center-to-corner zone ratio |
90% |
| Lens |
Optional (no lens included with this model) |
| Lens shift | Vertical(From the origin point of the lens mounter) |
±59 % (±56 % with ET-D75LE6 / ET-D3LEW60, +69 % – +84 % with ET-D75LE95) (powered) |
| Lens shift | Horizontal(From the origin point of the lens mounter) |
±29 % (±19 % with ET-D75LE6 / ET-D3LEW60, ±21 % with ET-D75LE95) (powered) |
| Keystone Correction Range |
Vertical: ±40° (± 22° with ET-D3LEW50, ±28° with ET-D75LE6 / ET-D3LEW60, +5° with ET-D75LE95),
Horizontal: ±15° (0° with ET-D75LE95) |
Keystone Correction Range with optional
ET-UK20 Upgrade Kit |
Vertical: ±45° (± 40° with ET-D75LE10 / ET-D3LEW10, ET-D75LE20 / ET-D3LES20, ±22° with ET-D3LEW50,
±28° with ET-D75LE6 / ET-D3LEW60, +5° with ET-D75LE95)
Horizontal: ±40° (±15° with ET-D3LEW50, ET-D75LE6 / ET-D3LEW60, 0° with ET-D75LE95),
When [VERTICAL KEYSTONE] and [HORIZONTAL KEYSTONE] are used simultaneously, correction cannot be made exceeding total of 55°. |
| Installation |
Horizontal/vertical, free 360-degree installation |
| Terminals | SDI 1 IN |
BNC x 1: 3G/HD/SD-SDI input, Dual-link HD-SDI (Link A), Dual-link 3G-SDI (Link 1),
Quad-link HD-SDI (Link 1), Quad-link 3G-SDI (Link 1) |
| Terminals | SDI 2 IN |
BNC x 1: 3G/HD/SD-SDI input, Dual-link HD-SDI (Link B), Dual-link 3G-SDI (Link 2),
Quad-link HD-SDI (Link 2), Quad-link 3G-SDI (Link 2) |
| Terminals | SDI 3 IN |
BNC x 1: 3G/HD/SD-SDI input, Dual-link HD-SDI (Link A), Dual-link 3G-SDI (Link 1),
Quad-link HD-SDI (Link 3), Quad-link 3G-SDI (Link 3) |
| Terminals | SDI 4 IN |
BNC x 1: 3G/HD/SD-SDI input, Dual-link HD-SDI (Link B), Dual-link 3G-SDI (Link 2),
Quad-link HD-SDI (Link 4), Quad-link 3G-SDI (Link 4) |
| Terminals | MULTI PROJECTOR SYNC IN |
BNC x 1 |
| Terminals | MULTI PROJECTOR SYNC OUT |
BNC x 1 |
| Terminals | Serial In |
D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| Terminals | Serial Out |
D-sub 9-pin (male) x 1 for link control (RS-232C compliant) |
| Terminals | REMOTE 1 IN |
M3 stereo mini-jack x 1 for wired remote control |
| Terminals | REMOTE 1 OUT |
M3 stereo mini-jack x 1 for link control |
| Terminals | REMOTE 2 IN |
D-sub 9-pin (female) x 1 for external control (parallel) |
| Terminals | DIGITAL LINK/LAN |
RJ-45 x 1 for network, DIGITAL LINK connection (HDBaseT compliant),
100Base-TX, compatible with Art-Net, PJLink (Class 2), Deep Color, HDCP 2.2 |
| Terminals | DC OUT |
USB Type A x 2 (for power supply DC 5 V total of 2 A) |
| Terminals | Expansion slot |
SLOT 1 / SLOT 2 (total two terminals, vacant) for interface boards, SLOT NX compatible |
| Power Supply |
AC 200 V–240 V, 8.5 A, 50/60 Hz
(Light output will decrease to approximately 50 % when using the projector with AC 100 V to AC 120 V [9.8A]) |
| Power Consumption |
1,650 W (0.3 W with Standby Mode set to ECO*6, 4 W with Standby Mode set to NORMAL) |
| Cabinet Materials |
Molded plastic |
| Operation noise |
46 dB |
| Dimensions (W x H x D) |
600 mm x 307 mm*7 x 745 mm ( 23 5/8˝ x 12 3/32˝ x 29 11/32˝ ) ( including protruding parts );
598 mm x 270 mm*8 x 725 mm ( 23 17/32˝ x 10 5/8˝ x 28 17/32˝ ) ( not including protruding parts ) |
| Weight |
54.0 kg (119 lbs) |
| Operating Environment |
Operating temperature: 0–45 °C (32–113 °F)*10, operating humidity: 10–80 % (no condensation) |
| Applicable Software |
Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software, Geometry Manager Pro (ET-UK20 Upgrade Kit, ET-CUK10 Auto Screen Adjustment Kit), Smart Projector Control for iOS/Android |
