Litepanels Sola Fresnel LED portable light

Litepanels Sola Fresnel Sola 6 - The Fresnel for the 21^st Century (906-2002)

Litepanels Focusable Fresnels Feature Breakthrough Technology
Litepanels brings the Fresnel into the 21st century with the new Sola™ series. With beam control of 70° to 10°, the revolutionary new Solas provide the controllability and single-shadow properties inherent in a Fresnel light, but utilize just a fraction the power of conventional fixtures.

Highly Controllable
Like all Litepanels, Sola Fresnels feature instant dimming from 100% to 0 with no noticeable color shift. The Sola6 provide on-fixture motorized control of focus and local dimming via a convenient touch screen, and are also remote-controllable via their integrated DMX interface. Output is fully flicker free, and remains consistent even as the battery voltage goes down.

Power Efficient and Lightweight
Employing Litepanels’ ultra-efficient LEDs, Solas draw 90% less power than conventional tungsten lights, with very little heat generation. Additionally, Litepanels’ cool-to-the-touch lighting systems substantially cut down on air conditioning requirements in studio applications. Importantly, the Solas weigh only 1/3 as much as their HMI predecessors with no external ballasts. The fixtures have a universal AC input and can be used on any 85-245 volt power worldwide.

Litepanels Solas
• The Sola6 draws 75 watts yet produces output equivalent to a 650W tungsten unit, and weighs 6 lbs. (2.7kg).

The most extensive range of LED Fresnels
In addition to the new Sola 12, the full Sola Series of LED Fresnels includes the Sola 6 (6” lens), Sola 4 (4” lens) and the Sola ENG (3” lens).

View Anton Bauer Battery Chart for
Sola 6
Litepanels Sola Fresnel LED
Product code: SOLAFRESNEL
Sola 6 9062002

Rethink Fresnel™ Litepanels Solas
Sola6

Sola6 Advantages

Proprietary Heat-free LED technology
Produces bright, HD friendly light
Integrated dimmer 100% to 0 with no noticeable color shift
Flicker-free light output
Eco-Friendly—Uses up to 95% less energy
50,000+ hours of LED life
Highly efficient
Lightweight
Instant restrike
No ballast necessary

Control Via

Traditional on-fixture knobs access motorized mechanical focus & electronic dimming
Screen shows dimming, focus, status, temperature, DMX address
Integrated DMX interface

Package Includes

Sola6 Fresnel LED Light Fixture
Mounting Yoke
Power Cable

Specifications

Sola6
Size: 6”x 7” x 9” (152mm x 178mm x 229mm)
Weight: 6 lbs. (2.7 kg)
Fresnel lens: 6 inch (15.24cm)
Power: 75W (equiv. to 650W tungsten)
Power Supply: internal universal PFC 85-245VAC

Sola6 Individual Gel

No	Type	Place your order here
1	410 - Opal Frost (900-6410)
2	204 Full CTO (900-6204)
3	205 1/2 CTO (900-6205)
4	206 1/4 CTO (900-6206)
5	223 1/8 CTO (900-6223)
6	Yoke Kit (Black) (900-6295)
7	Power Supply (900-6250)
8	D-Tap to 3-Pin XLR Female Cable (900-6251)
9	P-Tap to 3-pin XLR cable (900-0024)
10	Pole Operated Yoke (900-6203)
11	Fixture Cover (900-6222)
12	Daylight Fresnel EU Version (906-2102)

Optional Accessories
No Image	No Image	No Image
Sola6 8-Leaf Barn Door	Sola6 Filter Frame	Sola6 Pole Assisted Yoke
900-6221 (S68BD)	900-0006 (Discontinued) (S6FF)	900-6203
Less than USD 250	Less than USD 250	Less than USD 460


No Image	No Image
Sola 6 Gel Filter Set (5 pieces) with Carrying Bag	Sola 4/Sola 6 Gel Carrying Bag	RJ45 to 5-Pin XLR (Male) Conversion Cable
900-6201 (SOLA6GELCTOS)	900-6207 (SOLAGELBAG)	900-0006 (RJ45XLR)
Less than USD 195	Less than USD 80	Less than USD 75
