Directional
characteristics: |
Cardioid |
|
Principle of
operation: |
Pressure
gradient |
|
Cartridge type: |
Pre-polarized
condenser |
|
Frequency range: |
20 Hz - 20 kHz |
|
Frequency range, ± 2 dB, Near
field 2-3 cm (0.8-1.2 in): |
100 Hz - 20 kHz (4 –
6 dB soft boost at 15 kHz) |
|
Sensitivity, nominal, ± 3 dB at
1 kHz: |
6 mV/Pa; -44 dB re. 1
V/Pa |
|
Equivalent noise level,
A-weighted: |
Typ. 26 dB(A) re. 20
µPa (max. 28 dB(A)) |
|
Equivalent noise level, ITU-R
BS.468-4: |
Typ. 38 dB (max. 40
dB) |
|
S/N ratio (A-weighted), re. 1 kHz at
1 Pa (94 dB SPL): |
Typ. 68 dB(A) |
|
Total Harmonic Distortion
(THD): |
<1 % up to 123 dB SPL
peak; <1 % up to 120 dB SPL RMS sine |
|
Dynamic range: |
Typ. 97 dB |
|
Max. SPL, peak before
clipping: |
144 dB |
|
Output impedance: |
From MicroDot: 30 - 40
ohm. From DAD6001-BC: 100 ohm. |
|
Cable drive
capability: |
Up to 300 m (984 ft) with
DAD6001-BC XLR adapter |
|
Output balance
principle: |
Signal balanced with
DAD6001-BC XLR adapter |
|
Common Mode Rejection Ratio
(CMRR): |
> 60 dB from 50 Hz to
15 kHz with DAD6001-BC XLR adapter |
|
Power supply (for full
performance): |
For wireless systems: Min.
5 V through DPA adapter. . |
|
Current consumption: |
Typ. 1.5 mA (microphone).
3.5 mA with DAD6001-BC XLR adapter. |
|
Connector: |
MicroDot |
|
Color: |
Black, Brown or
Beige |
|
Weight: |
Single Ear: Microphone
boom: 1 g (0.035 oz). Earhook: 1 g (0.035 oz). Cable: 8 g (0.28
oz). Total: 10 g (0.35 oz) |
|
Microphone diameter: |
Length: 10 mm , Diameter:
5 mm |
|
Capsule diameter: |
5.4 mm (0.2
in) |
|
Microphone length: |
Boom length: 120 mm, 100
mm (M) |
|
Cable
length: |
1.25 m (4.1
ft) |
|
Cable color: |
Black, beige,
brown |
|
Cable diameter: |
1.6 mm (0.06
in) |
|
Polarity: |
+V at MicroDot pin for
positive sound pressure (and pin 2 on DAD6001-BC XLR
adapter) |
|
Temperature range: |
-40 °C to 45 °C
(-40 °F to 113 °F) |
|
Relative Humidity
(RH): |
Up to 90% |
