 Canon XF105 Flash Memory Camcorder

Home > Canon > Professional Video Camcorder > XF-105
  • Canon XF105 Flash Memory Camcorders
    Product Code: XF105
    Buy Sell Sales Canon XF105 Camcorder
    review button


  • Sennheiser ME 66 + K6

    Sennheiser ME66 +K6

    ME 66 + K6
    ME 66 Short gun Microphone Head + K6 Powering Module for Batter/Phantom Powering



Overview
Compact in size, light weight and fully featured, the Canon XF105 Professional Camcorder can be tailored to fit a wide range of individual needs. While sharing many of the capabilities of the Canon XF305 and XF300 Professional Camcorders, including the Canon XF Codec and Compact Flash (CF) recording, the XF105 offers some exciting new features of its own.

Whether used as a companion to the XF305 or XF300 or as a standalone camcorder, the XF105 is geared for a wide range of applications where high image quality, extreme portability, and efficient workflow are of the utmost importance. And with infrared recording and true stereoscopic 3-D production capabilities, the XF105 allows users to explore new creative outlets and emerging markets.

The XF105 utilizes Canon's XF Codec - a file-based MPEG-2 compression with an MXF File Wrapper that ensures the widest compatibility with existing industry infrastructure, metadata and non-linear editing (NLE) systems. The codec's 4:2:2 color sampling provides ultra-fine transitions in tone and color for maintaining the highest image quality needed for advanced post production processing.

The XF105's newly developed Genuine Canon 10x HD Video Lens along with a Canon native 1920 x 1080 CMOS Image Sensor delivers exceptional image quality. The XF105 also offers multiple recording bit rates, resolutions and variable frame rates to expand creative flexibility, allowing users to work in virtually any production environment.

Incorporating industry-standard HD-SDI output, genlock input SMPTE time code input/output terminals makes the Canon XF105 perfectly matched for live application and multi-camera shooting.

Features
- MPEG-2 recording to 2 CF cards at up to 50Mbps (4:2:2)
- Light, compact design; XLR inputs
- 10x zoom Canon HD Video Lens
- 1/3 type Full HD Canon CMOS
- HD-SDI, Timecode, Genlock; 3D Assist Functions
- 8.8cm (3.5") 920k dot LCD; 0.6cm (0.24"), 260k dot EVF
- Variable frame rates
- An unprecedented combination of versatility and Full HD image quality

MPEG-2 recording at up to 50Mbps (4:2:2)
The XF105 records MPEG-2 MXF (Media eXchange Format) files - up to 1920 x 1080 Full HD at 50Mbps (4:2:2) - to relatively inexpensive and widely available CompactFlash (CF) memory cards. Relay Recording across two card slots allow filming to continue without interruption, whilst Double Slot Recording lets you store the same footage to both cards.

Light, compact design; XLR inputs
Putting exceptional functionality in the palm of your hand, the durable and lightweight design enables exceptional versatility. Linear PCM audio can be captured via twin XLR inputs and also using the front-mounted stereo microphone.

10x zoom Canon HD Video Lens
Drawing on Canon's broadcast lens expertise, XF105 features a fast, wide angle Canon HD Video Lens (f1.8-f2.8, 30.4mm) with built-in control ring for adjustment of zoom, focus or iris. An enhanced Optical Image Stabilizer system helps to reduce chromatic aberration, maintain sharpness and reduce lens size.

1/3 type Full HD Canon CMOS
A 2.07MP Full HD CMOS sensor - designed and manufactured by Canon - captures Full HD video at native 1920x1080 resolution. The sensor is equipped with a Bayer pattern colour filter for high sensitivity and wide dynamic range; high-speed data readout technology minimises rolling-shutter skew that can occur in CMOS camcorders.

HD-SDI, Timecode, Genlock; 3D Assist Functions
HD-SDI output is the industry standard, outputting uncompressed Full HD with embedded audio and Timecode. A combined Genlock In and Timecode In/Out terminal allows the XF105 to be used in a multi-camera shoot. Genlock and 3D Shooting Assist functions (OIS Axis Shift and Focal Length Guide) support stereoscopic 3D video capture using two camcorders.

8.8cm (3.5'') 920k dot LCD; 0.6cm (0.24"), 260k dot EVF
Both camcorders feature a large, side-mounted LCD. This 8.8cm (3.5") screen has a sharp, 920k dot resolution, with a built-in waveform monitor and Edge Focus function to help set up the shot. A 0.61cm (0.25''), 260k dot EVF with 100% coverage is also available.

Variable frame rate

A wide range of frame rates is available, from 12 to 50 fps. This gives cameramen the freedom to alter the capture rate for additional creative flexibility.


Specifications

Recording System Movies Video compression: MPEG-2 Long GOP;
Audio compression: Linear PCM, 16 bits, 48 kHz, 2 channels
File type: MXF
Photos Image compression: JPEG
DCF (Design rule for Camera File system), compatible with Exif Ver. 2.2
Video Configuration (recording/playback) 50 Mbps
(CBR, 4:2:2, 422P@HL)
1920x1080: 50i, 25P
1280x720: 50P, 25P
35 Mbps
(VBR, 4:2:0, MP@HL)
1920x1080: 50i, 25P
1280x720: 50P, 25P
25 Mbps
(CBR, 4:2:0, MP@H14)
1440x1080: 50i, 25P
Recording Media (not included) Movies CompactFlash (CF) Card Type I (two slots)
Photos (*1) SD or SDHC (SD High Capacity) memory card
Maximum Recording Time (*2) 16 GB CF Card
50 Mbps: 40 min., 35 Mbps: 55 min., 25 Mbps: 80 min.
64 GB CF Card
50 Mbps: 160 min., 35 Mbps: 225 min., 25 Mbps: 310 min.
Image Sensor 1/3-type CMOS, approx. 2,070,000 pixels (1920x1080)
LCD screen 8.8 cm (3.5 in.), wide, color, approx. 920,000 dots
Viewfinder 0.61 cm (0.24 in.), approx. 260,000 dots equivalent
Microphone Stereo electret condenser microphone
Lens f=4.25-42.5 mm, F1.8-2.8, 10x optical zoom
35 mm equivalent: 30.4-304 mm
Lens Configuration 12 elements in 10 groups (2 single-sided aspheric elements)
ND filter Built-in gradation ND filter
Filter diameter 58mm
AF System Autofocus (TTL + external distance sensor when set to [Instant]) or Manual focus using manual ring
White Balance Auto white balance, custom white balance, preset white balance settings or color temperature setting
Iris Auto or manual setting
Gain Auto (AGC) or manual (-6.0 dB to 33.0 dB, fine-tuning available)
Shutter speed Auto, speed, angle, clear scan or slow shutter mode, off; 1/3 sec to 1/2000
Minimum Illumination

0.08 lux
(CAMERA switch set to M (manual), [Frame Rate] at [50i], gain at 33 dB, shutter speed at 1/3)
Subject Illumination Range 0.08 to 10,000 lux (when the [Frame Rate] is [50i])
Image Stabilization Optical-Shift Image Stabilizer
Size of Video Recordings 50 Mbps, 35 Mbps 1920x1080 pixels, 1280x720 pixels
25 Mbps 1440x1080 pixels
Size of Photos 1920x1080, 1280x720 (only when capturing a photo from a clip)
Terminals
HD/SD SDI Terminal BNC jack, output only, 0.8 Vp-p/75 Ω, unbalanced
HD-SDI SMPTE 292M
Video (1080i/720P), embedded audio, time code (VITC/LTC)
SD-SDI SMPTE 259M
Video (576i), embedded audio, time code (VITC/LTC)
HDMI OUT Terminal HDMI connector, output only
HD/SD COMPONENT OUT Terminal 720P (D4)/1080i (D3)/576i (D1) compatible, output only
Luminance (Y): 1 Vp-p / 75 Ω
Chrominance (Pb /Pr ): ±350 mV / 75 Ω
AV Terminal φ 3.5 mm mini jack (audio and video), output only
Video 1 Vp-p / 75 Ω unbalanced
Audio -10 dBV (47 kΩ load, output level 1Vrms) / 3 kΩ or less
XLR Terminal XLR jack (pin1: shield, pin2: hot, pin3: cold), 2 sets
Sensitivity
MIC setting: -60 dBu (manual volume center, full scale -18 dB) / 600 Ω
LINE setting: 4 dBu (manual volume center, full scale -18 dB) / 10 kΩ
Microphone attenuator: 20 dB
MIC Terminal φ3.5 mm stereo minijack (unbalanced)
Sensitivity: 60 dBu (manual volume center, full scale -18 dB)
Microphone attenuator: 20 dB
(Headphone) Terminal φ3.5 mm stereo mini-jack, to -12 dBV (16 Ω load, volume range Min to Max) / 50 Ω or less
GENLOCK/TC Terminal BNC jack
As GENLOCK terminal Input only: 1 Vp-p/75 Ω
As TC (time code) terminal Input: 0.5 V - 18 Vp-p/10 kΩ
Output: 1 Vp-p/75 Ω
REMOTE Terminal φ2.5 mm stereo mini-jack
USB Terminal mini-B, USB 2.0 (Hi-Speed USB)
Power/Others
Power supply (rated) 7.4 V DC (battery pack), 8.4 V DC (DC IN)
Power consumption
(Recording at 50 Mbps with AF on, viewfinder/LCD screen normal brightness, SDI output off)
Viewfinder: 6.1 W, LCD screen: 6.2 W
Operating temperature 0 - 40 °C
Dimensions (W x H x D) 121 x 148 x 250 mm (4.8 x 5.8 x 9.8 in.) (excluding lens hood, microphone holder unit, grip belt)
Weight
(camcorder body only)
 1,070 g


What's in the box
- XF105 Camcorder with Lens Cap
- Lens Hood
- Battery Pack BP-925
- Compact Power Adapter CA-930
- DC Cable DC-930
- Wireless Controller WL-D6000
- Shoulder Strap SS-1200
- Microphone Holder Unit
- Component Cable CTC-100/S
- Canon XF Utilities Disc
