Sony Headphone |
MDR-7506
|
|
HXR-MC2500: Overview
The Sony HXR-MC2500 provides a professional look and shooting style which is ideal for weddings, corporate communications or education
facilities. While light and easily portable, its full Shoulder Mount design means your clients immediately know you mean business.
Workflow flexibility is enhanced by the ability to record directly onto a
removable memory card or a 32GB internal flash memory storage system in High Definition or Standard Definition. With this combination of the internal flash memory and memory card allows recording functions such as "Relay" and
"Simultaneous" are available. When Sony's L-Series Info Lithium battery NP-F970 (optional) is used, the Sony HXR-MC2500 is capable of continuous long recording of up to 14 hours- perfect for those occasions where you don't want to stop
recording, such as weddings or business conferences.
NOTE: Depending on your region, the Sony HXR-MC2500 is available in PAL or NTSC models to ensure the best possible performance. See
specification for more details
Features Wide-angle G Lens
The
Sony HXR-MC2500 comes equipped with a sophisticated G Lens that incorporates Sony's unique optical design technology and quality control, delivering exceptional performance on a par with some of the best lenses in the industry.
The Sony HXR-MC2500 itself is optimized to perfectly complement the G Lens with an advanced image sensor and Sony's famous image
processing technology. This improves picture performance whether zooming in on the action, or getting a perspective on the big picture with a 26.8mm* lens offering the widest angles in this
class of camera, which enables wide-angle shooting even in tight spaces.
*35mm or equivalent
Highly-sensitive Exmor™ R CMOS sensor and
built-in LED light
The Sony HXR-MC2500 is capable of shooting clearly even in low-light or indoor environments. Its highly-sensitive Exmor™ R CMOS sensor adopts a back-illuminated technology that enables the
image sensor to utilize incidental light more efficiently, helping the video-grapher to achieve rich image quality even during low-light shooting situations. Moreover, the Sony HXR-MC2500 is
also equipped with a convenient built-in LED light for valuable extra illumination when needed.
Wide angle view, high contrast OLED viewfinder and 3-inch wide LCD panel
The Sony HXR-MC2500 is equipped with an OLED
Tru-Finder™ electronic viewfinder, offering a high resolution of approximately 1.44 million dots with high contrast levels. Sony's proprietary viewfinder technologies allow for better tonal
reproduction and more detailed picture information when shooting. In addition, there is also the built-in 3-inch wide high resolution LCD panel (approximately 0.92 million dots) for crisp and bright
views.
Wi-Fi/NFC functions for seamless connection to smart phones
The Sony HXR-MC2500 can connect to mobile devices such as smart phones or tablets via a Wi-Fi connection, enabling
monitoring and remote control functions such as start/stop recording, zoom control, iris control and touch auto focus. Furthermore, it is also NFC-capable (Near Field Communications) to
allow easy, one-touch wireless connections to compatible mobile devices.
Multi-Interface (MI) Shoe
The Sony HXR-MC2500 MI Shoe expands your options to use accessories without cables, such as the UWP-D11 wireless microphone receiver and XLR audio input by XLR adapter.
|
Specifications
| General |
| Mass |
Approx 2.80kｇ (body) |
| Approx. 6lb 2.8oz (body) |
| Approx. 3.10kg (with lens hood, Lens Cap, Microphone, Eyecup, Shoe Cap, NP-F570 battery) |
| Approx. 6lb 13.3oz (with lens hood, Lens Cap, Microphone, Eyecup, Shoe Cap, NP-F570 battery) |
Dimension
(W x H x D) |
265.0 ｘ 235.0 ｘ 455.0 mm (body) |
| 10 1/2 x 9 3/8 x 18 inches (body) |
| 265.0 ｘ 240.0 ｘ 460.0 mm (With the accessories (lens hood, Lens Cap, Microphone, Eyecup), excluding the grip belt and including the projecting parts) |
| 10 1/2 x 9 1/2 x 18 1/8 inches (With the accessories (lens hood, Lens Cap, Microphone, Eyecup), excluding the grip belt and including the projecting parts) |
| Power requirements |
7.2V (battery pack); 8.4V (AC Adaptor) |
| Power consumption |
Approx. 3.3 W (with EVF On, Video light Off) |
| Approx. 3.3 W (with LCD monitor On, Video light Off) |
| Operating temperature |
0°C to 40°C (32°F to 104°F) |
| Storage temperature |
-20°C to +60°C (-4°F to +140°F) |
| Battery operating time |
Approx. 285 min with NP-F570 battery (video light Off)
Approx. 135 min with NP-F570 battery (video light On) |
| Recording format |
Video Format HD |
MPEG4-AVC / H. 264 AVCHD format Ver.2.0 compatible |
| Video Format SD |
DV(AVI) |
| Audio Format HD |
Linear PCM 2ch, 16bit, 48kHz / Dolby Digital 2ch, 16bit, 48kHz |
| Audio Format SD |
Linear PCM 2ch, 16bit, 48kHz |
| Recording frame rate |
(NTSC) - HD |
PS(28Mbps) 1920 x 1080/60P, 16:9
FX(24Mbps) 1920 x 1080/60i, 30p,24p, 16:9, 1280 x 720/60p, 16:9
FH(17Mbps) 1920 x 1080/60i, 30p,24p, 16:9, 1280 x 720/60p, 16:9
HQ(9Mbps) 1280 x 720/60p, 16:9 |
| (NTSC) - SD |
DV(25Mbps) 720 x 480/60i, 16:9, 4:3 |
| (PAL) - HD |
PS(28Mbps) 1920 x 1080/50P, 16:9
FX(24Mbps) 1920 x 1080/50i, 25p, 16:9, 1280 x 720/50p, 16:9
FH(17Mbps) 1920 x 1080/50i, 25p, 16:9, 1280 x 720/50p, 16:9
HQ(9Mbps) 1280 x 720/50p, 16:9 |
| (PAL) - SD |
DV(25Mbps) 720 x 576/50i, 16:9, 4:3 |
| Recording/Playback time |
Approx.145min(Internal Media, PS, LPCM)
Approx.170min(Internal Media, FX, LPCM)
Approx.225min(Internal Media, FH, LPCM)
Approx.380min(Internal Media, HQ, LPCM)
Approx.140min(Internal Media, DV, LPCM) |
| Lens |
| Lens Mount |
Fixed |
| Zoom Ratio |
12x (optical), servo/manual |
| Focal Length |
f = 2.9-34.8mm
equivalent to f=26.8-321.6mm on 35 mm lens(16:9)
equivalent to f=32.8-393.6mm on 35 mm lens(4:3) |
| Iris |
F1.8 - F3.4 auto/manual selectable |
| Focus |
AF/MF selectable, 10 mm to ∞ (Wide), 800 mm to ∞ (Tele)l |
| Image stabilizer |
ON(Standard/ACTIVE)/OFF selectable, shift lens |
| Filter Diameter |
M37 mm |
| Camera Section |
| Imaging Device |
(Type) |
1/3.95 type(4.6mm) back-illuminated Exmor R CMOS Sensor |
| (Pixel Count) |
Approx.6590K pixels |
| Effective Picture Elements |
Approx.6140K pixels(16:9)/Approx.4600K pixels(4:3) |
| Minimum illumination |
1.4lux(MAN setting : SS 1/25sec , Iris F1.8 , Gain 33dB)
0.7lux(MAN setting : SS 1/12sec , Iris F1.8 , Gain 33dB) |
| Shutter speed |
1/6 - 1/10,000 |
| White balance |
Preset（Indoor, Outdoor, Color temperature set range:2300-15000K) Onepush A, B, Auto selectable |
| Gain |
0, 3, 6, 9, 12, 15, 18, 21, 24, 27, 30, 33 dB, Auto Selectable |
| Inputs/Outputs |
| Composite Output |
BNC (x1) |
| Audio Output |
RCA pin |
| USB |
mini-AB USB2.0 Hi-speed/mass-storage/Host |
| Headphone Output |
Stereo mini jack φ3.5mm (x1) |
| Speaker Output |
Monaural |
| DC Input |
DC jack |
| Remote |
Stereo mini mini jack φ2.5mm (x1) |
| HDMI Output |
Type A (x1) |
| Accessory Shoe |
Multi Interface Shoe (x1), Cold Shoe (x2) |
| Monitoring |
| Viewfinder |
1.0cm (0.39 type) OLED Approx. 1.44M dots |
| Built-in LCD monitor |
7.5cm (3.0 type) Approx. 921K dots |
| Built-in Microphone |
| Built-in Microphone |
Omni-directional stereo electret condenser microphone. |
| Media |
| Internal Memory |
Flash Memory 32GB |
| Type |
Memory Stick Pro Duo™ and SD/SDHC/SDXC compatible |
| Built-in LED Light |
| Luminous intensity |
1.0m / Approx.200 lx, 0.5m / Approx.800lx |
| Lighting angle |
Approx. 30° |
| Color temperature |
PApprox. 5,500K |
| Wifi |
| Supported format |
IEEE 802.11 b/g/n |
| Frequency band |
2.4 GHz bandwidth |
| Security |
WEP/WPA-PSK/WPA2-PSK |
| NFC |
NFC Forum Type 3 Tag compliant |
|
Supplied Accessories
- Lens cap (1)
- Shoe Cap (1)
- EVF eyecup (1)
- Microphone (1)
- Wind screen (1)
- Video Light Diffuser (1)
- USB adaptor cable (1)
- Rechargeable battery pack (NP-F570) (1)
- CD-ROM Operating instructions in PDF (1)
- Operating instructions (1)
- AC-L100C AC adaptor (1)
- AC Cable (1)
- Warranty (1) |
|
|
|
