Flexibility and Performance to Meet Your Needs
Why Choose Panasonic?
People choose
Panasonic because our products are highly dependable and meet the needs of professionals and
educators. The versatile PT-EX620 Series, for example,
serves up immersive pictures in almost any situation,
plug-and-play, with uncommonly low running costs. Like you, Panasonic projectors are working hard to
deliver
results of the highest quality.
Natural Pictures in Bright Rooms
More than 30 years of hard-won experience stands behind
every Panasonic projector we make. Innovative technology guarantees uncommonly bright and vivid pictures even in well-lit rooms.
System
Flexibility
Long-reach single-cable AV control, powered lens shift / zoom / focus, and wide compatibility with existing infrastructure simplify and
streamline setup for permanent or portable installations.
Low Total Cost of Ownership
From dust-resistant construction to
long-life UHM lamp, the PT-EX620 Series is engineered for trouble-free operation with very low maintenance, saving you time and money.
* To operate
wireless projection, the optional Wireless Module ET-WML100 is required. |
| Power supply |
100-240 V AC, 50/60 Hz |
| Power consumption |
461 W, (424 W with LAMP POWER set to NORMAL, 305 W with LAMP POWER set to ECO),
(0.5 W when STANDBY MODE set to ECO*1, 12 W when STANDBY MODE set to NORMAL) |
| LCD panel |
Panel size |
16.0 mm (0.63 in) diagonal (4:3 aspect ratio) |
| Display method |
Transparent LCD panel (x 3, R/G/B) |
| Drive method |
Active matrix |
| Pixels |
786,432 (1,024 x 768) x 3, total of 2,359,296 pixels |
| Lens |
PT-EX620 |
1.8x powered zoom (throw ratio 1.32-2.44:1), powered focus F 1.6-2.2, f 17.1-31.7 mm |
| PT-EX620L |
Optional powered zoom/focus lenses and fixed-focus lens |
| Lamp |
320 W UHM lamp x 1,
lamp replacement cycle (lamp power: NORMAL / ECO): 4,000 hours / 5,000 hours*2 |
| Screen size (diagonal) |
1.05-10.77 m (40-400 in), 4:3 aspect ratio |
| Brightness*3 |
6,200 lm (lamp power: NORMAL, Dynamic Mode, Iris: OFF, Daylight View: OFF, Auto Power Save: OFF) |
| Center-to-corner uniformity*3 |
90 % |
| Contrast*3 |
10,000:1 (lamp power: NORMAL, Dynamic Mode, Iris: ON, Daylight View: OFF, Auto Power Save: OFF) |
| Resolution |
1,024 x 768 pixels*4 |
Scanning
frequency |
HDMI/
DIGITAL LINK |
fH: 15-90 kHz, fV: 24-100 Hz, Dot clock: 25-162 MHz, compatible with HDCP, |
| RGB |
fH: 15-90 kHz, fV: 24-100 Hz, Dot clock: up to 162 MHz |
| YPBPR (YCBCR) |
fH: 15.73 kHz, fV: 59.94 Hz [480i (525i)]
fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH:
33.75 kHz, fV: 60 Hz [1080 (1125)/60i]
fH: 28.13 kHz, fV: 25 Hz [1080 (1125)/25p]
fH: 27.00 kHz, fV: 48 Hz [1080 (1125)/24sF]
fH: 67.50 kHz, fV:
60 Hz [1080 (1125)/60p]
fH: 31.47 kHz, fV: 59.94 Hz [480p (525p)]
fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
fH: 27.00 kHz, fV: 24 Hz [1080 (1125)/24p]
fH: 33.75 kHz, fV: 30 Hz [1080 (1125)/30p]
fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p] |
| Video/YC fH: |
fH: 15.73 kHz, fV: 59.94 Hz [NTSC / NTSC4.43 / PAL-M / PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL / PAL-N / SECAM] |
| Optical axis shift |
Vertical |
±50 % from center of screen (powered) |
| horizontal |
±30 % from center of screen (powered) |
| Keystone correction range*5 |
Vertical ±25°, horizontal ±30° |
| Installation |
Ceiling/floor, front/rear |
| Built-in speaker |
4.0 cm round shape x 1, output power 10.0 W (monaural) |
| Terminals |
HDMI IN |
HDMI 19-pin x 2 (Deep Color, compatible with HDCP),
audio signal: Linear PCM (Sampling frequency: 48 kHz / 44.1 kHz / 32 kHz) |
| RGB 1 IN |
BNC x 5 (RGB or YPBPR / YCBCR x 1) shared with VIDEO IN (S-video / composite video) |
| RGB 2 IN |
D-Sub HD 15-pin (female) x 1 |
| VIDEO IN |
Pin jack x 1 (composite video) |
| MONITOR OUT |
D-sub HD 15-pin (female) x 1 (RGB x 1) (compatible with RGB or YPBPR / YCBCR) |
| AUDIO IN |
Pin jack x 2 (L/R x 1), M3 x 2 (L-R x 2) |
| AUDIO OUT |
M3 x 1 (L-R x 1) for output (variable) |
| SERIAL IN |
D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| REMOTE 1 IN |
D-sub 9-pin (female) x 1 for external control (parallel) |
| REMOTE 2 IN |
M3 x 1 for wired remote control |
| LAN |
RJ45 x 1 (for network connection, 10Base-T, 100Base-TX, compliant with PJLink™) |
DIGITAL LINK /
LAN |
RJ-45 x 1 (for network and DIGITAL LINK (video / audio / network / serial control) connection,
100Base-TX, compliant with PJLink™, HDCP compatible, Deep Color compatible) |
| USB-A |
USB terminal for optional Wireless Module (ET-WML100) x 1,
DC output terminal for power supply (DC 5 V, up to 900 mA) x 1 |
| Operation noise*3 |
35 dB (lamp power: NORMAL), 29 dB (lamp power: ECO) |
| Filter |
x 1, recommended replacement cycle: 15,000 hours*6 |
| Mechanical shutter |
Yes |
| Cabinet materials |
Molded plastic (PC + ABS) |
Dimensions
(W x H x D) |
PT-EX620 |
498 x 145*7 x 398.3 mm (19-19/32 x 5-11/16*7 x 15-11/16 in) (with supplied lens) |
| PT-EX620L |
498 x 145*7 x 358 mm (19-19/32 x 5-11/16*7 x 14-3/32 in) (with supplied lens) |
| Weight*8 |
PT-EX620 |
Approximately 8.4 kg (18.5 lbs) (with supplied lens) |
| PT-EX620L |
Approximately 7.7 kg (17.0 lbs) (without lens) |
| Operating environment |
Operating temperature: 0-45 °C (32-113 °F)*9,
operating humidity: 20-80 % (no condensation) |
| Supplied accessories |
Power cord (including power cord holder) x 1*10,
wireless remote control unit x1, batteries for remote control (AAA / R03 / LR03 type) x 2,
software CD-ROM (Logo Transfer Software, Multi Monitoring & Control Software) x 1 |
Note:The PT-EX620L/EX520L delivers the same performance as the PT-EX620 /
EX520, but comes without a lens.
*1 When Standby Mode is set to Eco, network functions such as power on over LAN will not operate.
Also, only certain commands can
be received for external control using the serial terminal.
*2 This is the maximum value when the lamp is turned on for 2 hours and off for 0.25 hours. If
the lamp is turned on more frequently or kept on for a long time, lamp replacement cycle will be reduced. Usage environment affects the duration of the
lamp.
*3 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*4 Input signals that exceed
supported resolution will be converted.
*5 With the supplied lens. Value differs when the correction for both directions is operated.
*6 Usage
environment affects the duration of the filter.
*7 With legs at shortest position.
*8 Average value. May differ depending on models.
*9 At
altitudes below 1,400 m (4.593 ft) above sea level. Operating temperature range is 0 °C to 40 °C (32 °F to 104 °F) when used at altitudes from 1,400 m to 2,700
m (4,593 ft to 8,858 ft) above sea level. Also, if ambient temperature exceeds 40 °C (104 °F) (35 °C [95 °F] at high altitude), lamp power automatically
switches to Eco to in order to protect the projector.
*10 Power cords available (x2) for Europe, the UK and Asia only.
NOTES ON USE
1. Do not install the projector in locations that are subject to excessive water, humidity, steam, or oily smoke. Doing so may result in fire, malfunction,
or electric shock.
2. The projector uses a high-voltage mercury lamp that contains high internal pressure. This lamp may break, emitting a loud sound, or
fail to illuminate, due to impact or extended use.
3. The projector uses of high-wattage lamp that becomes very hot during operation. Please observe the
following precautions:
• Never place objects on top of the projector while it is in operation.
• Make sure there is an unobstructed space of 1,000 mm
(39-3/8 in) or more around the projector's exhaust openings.
• Do not stack projector units directly on top of one another for the purpose of multiple
(stacked) projection. When stacking projector units, be sure to provide the amount of space indicated between them. These space requirements also apply to
installation where only one projector unit is operating at one time and the other unit is used as a backup.
• If the projector is placed in a box or
enclosure, the temperature of the air surrounding the projector must match the operating temperature listed in the specifications table during use. Also, make
sure the projector’s intake and exhaust openings are not blocked. Ensure there is sufficient ventilation to prevent hot air from the exhaust openings being
recirculated into the intake opening.
4. The lamp replacement cycle duration becomes shorter if the projector is operated repeatedly for short periods.
•
The lamp replacement cycle varies greatly depending on individual lamp characteristics and usage conditions.
• The brightness of the lamp will
gradually decrease with use.
• The usage environment affects the lamp replacement cycle.
5. Due to natural characteristics of lamps, screen
brightness may fluctuate. This is not an indication of faulty lamp performance. |
|
|
