Specifications:
| Formats |
3Gb, 1.5Gb, 270Mb, Auto Select |
| Video Inputs and Outputs |
SDI (SMPTE 259/292/424), BNC
1x Single mode optical fiber, LC connector (FiDO-R, FiDO-T)
1x Single mode optical fiber, ST connector (FiDO-T-ST, FiDO-R-ST)
1x Single mode optical fiber, SC connector (FiDO-T-SC, FiDO-R-SC)
2x Single mode optical fiber, LC connectors (FiDO-2R, FiDO-2T, FiDO-TR)
4x Single mode optical fiber, ST connectors (FiDO-4R-ST, FiDO-4T-ST) |
Cable Equalization
(BNC Inputs, 1694 coax) |
270mb, 400m
1.5Gb, 200m
3Gb, 140m |
| Input/Output Return Loss (BNC) |
>15db, 270Mb - 3Gb |
| Optical Outputs |
Wavelength: 13 10 nm
Output Power: -2dBm typical |
| Size |
4.6" x 1.71 " x.85" (117 x 43.5 x 21.6mm) - FiDO-T, FiDO-R, FiDO-T-ST, FiDO-R-ST, FiDO-T-SC, FiDO-R-SC, FiDO-2R, FiDO-2T, FiDO-TR
4.6" x 4.10" x 0.92" (117 x 105 x 24mm) - FiDO-4T-ST, FiDO-4R-ST |
| Power |
+5-20 VDC
1.5 watts (FiDO-T, FiDO-R, FiDO-T-ST, FiDO-R-ST, FiDO-T-SC, FiDO-R-SC)
2.5 watts (FiDO-2R, FiDO-2T, FiDO-TR)
4.0 watts (FiDO-4R-ST, FiDO-4T-ST)
Requires Power Supply (AJA power supply model DWP-U-R1 included) |
|
