Power
supply |
100-240
V AC,
50/60 Hz |
|---|---|
|
Power
consumption |
300
W
(Approx.
4 W in
standby
mode
with fan
stopped) |
|
LCD
panel |
|
|
Panel
size |
0.63"
(16 mm)
diagonal, 4:3 aspect ratio |
|
Display
method |
Transparent LCD panel (x 3, R/G/B) |
|
Drive
method |
Active matrix |
|
Pixels |
1,024 x 768 (x 3) |
|
Lens |
Manual
zoom
(1:1-1:1.2),
manual
focus, F 1.65-1.93, f 18.53–22.18 mm |
|
Throw
ratio |
1.4
-1.7:1 |
|
Lamp |
220
W UHM™
lamp |
|
Projection
size
(diagonally) |
33-300
inches (4:3 aspect ratio) |
|
Colours |
Full
colour
(16,777,216
colours) |
|
Brightness*
1 |
2,600
lumens |
|
Centre-to-corner
uniformity*
1 |
85 % |
|
Contrast
ratio*
1 |
500:1
(full on
/full
off) |
|
Resolution
(RGB) |
1,024 x
768*2 |
|
Scanning
frequency |
|
|
RGB |
Horizontal: 15-91 kHz, Vertical: 50-85 Hz |
|
YPBPR |
480i (525i): fH 15.75 kHz; fV 60 Hz |
| 480p (525p): fH 31.5 kHz; fV 50 Hz | |
| 576i (625i): fH 15.63 kHz; fV 60 Hz | |
| 576p (625p): fH 31.25 kHz; fV 50 Hz | |
| 720p (750p): fH 45.00 kHz; fV 60 Hz | |
| 720p (750p): fH 37.50 kHz; fV 50 Hz | |
| 1080i (1125i): fH 33.75 kHz; fV 60 Hz | |
| 1080i (1125i): fH 28.13 kHz; fV 50 Hz | |
|
S-Video/Video |
NTSC, NTSC4.43, PAL-M, PAL60: fH 15.75 kHz; fV 60 Hz |
| PAL, SECAM, PAL-N: fH 15.63 kHz; fV 50 Hz | |
|
Optical
axis
shift |
5:1
(fixed) |
|
Keystone
correction
range |
Vertical:
±30° |
|
On-screen
menu |
17
languages:
English,
French,
German,
Spanish,
Italian,
Korean,
Russian,
Chinese,
Japanese, Swedish, Norwegian, Danish, Portuguese, Polish, Hungarian, Czech, and Thai |
|
Installation |
Front/rear
ceiling/desk
(menu
selection) |
|
Built-in
speakers |
1.0
W
(monaural)
output
power |
|
Terminals |
|
|
COMPUTER
1 IN |
D-sub HD 15-pin x 1 |
|
COMPUTER
2 IN/1
OUT |
D-sub HD 15-pin x 1 (input/output selectable using on-screen menu) |
|
VIDEO IN |
RCA pin x 1 |
|
S-VIDEO
IN |
Mini DIN 4-pin x 1 |
|
AUDIO IN |
RCA (L-R) x 1 (for VIDEO/S-VIDEO) |
|
COMPUTER
AUDIO IN |
M3 (stereo) x 1 |
|
VARIABLE
AUDIO
OUT |
M3 (stereo) x 1 |
|
SERIAL |
D-sub 9-pin x 1 (RS-232C) |
|
Power
cord
length |
2 m
(6'7") |
|
Cabinet
material |
Moulded
plastic
(PC+ABS) |
|
Dimensions*
4
(W x H x
D) |
368
x 88 x
233 mm
(14-1/2"
x
3-15/32"
x
9-3/16") |
|
Weight |
2.96
kg (6.5
lbs.) |
|
Operation
environment |
|
|
Temperature |
0°-40°C (32°-104°F) |
|
Humidity |
20%-80% (no condensation) |
|
Wireless
LAN |
|
|
Standard |
IEEE802.11b/g |
|
Operation
range*
5 |
Approx. 30 m (98'5") |
|
Infrastructure
mode |
WPA-PSK
(TKIP/AES), 128/64-bit WEP |
|
Ad-hoc
mode |
128/64-bit WEP |
|
Wireless
remote
control
unit |
|
|
Power
supply |
3 V DC (AA battery x 2) |
|
Operation
range*
5 |
Approx. 15 m (49'3" feet) when operated from directly in front of the signal receptor |
|
Dimensions
(W x H x
D) |
48 x 163 x 24.5 mm (1-7/8" x 6-13/32" x 31/32") |
|
Weight |
117 g (4.2 oz) (including batteries) |
|
Supplied
accessories |
Power
cord,
power
cord
secure
lock,
wireless
remote
control,
batteries
for
remote
control,
VGA
cable,
carrying
bag,
Wireless
Manager
ME 5.0
(CD-ROM) |
|
Optional
accessories |
ET-LAB80
Replacement
lamp
unit,
ET-PKB80
Ceiling
mount
bracket |
*1:
Measurement,
measuring
conditions, and
method of
notation all
comply with ISO
21118
international
standards.
*2: Input signals that exceed this resolution will be converted to 1,024 x 768 pixels.
*3: Input signals that exceed this resolution will be converted to 1,280 x 800 pixels.
*4: Including protruding parts.
*5: Operation range differs depending on the environment.
*2: Input signals that exceed this resolution will be converted to 1,024 x 768 pixels.
*3: Input signals that exceed this resolution will be converted to 1,280 x 800 pixels.
*4: Including protruding parts.
*5: Operation range differs depending on the environment.
